| Positioning system | GPS + IRNSS + GLONASS |
|---|---|
| Positioning accuracy | <2.5m CEP |
| Tracking sensitivity | -163dBm |
| Acquisition sensitivity | -147dBm |
| TTFF (open sky) | Avg. hot start ≤2sec |
| Avg. cold start ≤32sec | |
| LED Indication | Red (Power), Blue (GPS), Green (GSM) |
| Communication network | GSM |
|---|---|
| Frequency | 850/900/1800/1900 MHz |
| GPRS | Class 12, TCP/IP |
| Phase error | RMSPE<5, PPE<20 |
| Max output | GSM850/GSM900: 33±3dBm |
| GSM1800/GSM1900: 30±3dBm | |
| Max frequency error | ±0.1ppm |
| Receiving sensitivity | Class IIRBER2% (-106dBm) |
| Sim type | Esim |
| Battery | 450mAh/3.7V Industrial lithium polymer battery |
|---|---|
| Input voltage | 9-36V DC |
| Standby current | ≤5mA (by battery) |
| Standby time | 60 hours |
| Working time | 5 hours |
| Dimensions | 98.5 x 52.0 x 15.0mm |
|---|---|
| Weight | 80g |
| Operating temperature | –20℃ to +70℃ |
|---|---|
| IP rating | IP66 |
| LED indication | GNSS (Blue), Cellular (Green), Power (Red) |
|---|---|
| Data storage | 32+64MB |
| Antenna | Built-in GPS ceramic antenna, GSM quad-band antenna |
| Driving behavior analysis | Harsh acceleration, Harsh braking, Harsh cornering, Collision |
|---|---|
| Logs storage | 50K |
