LG300 | Magnet Tracker

LG300 is a 2G wireless tracker designed to handle industrial and commercial applications ranging from rental agencies and fleet management to freight transportation and more. Featuring multiple positioning systems and a high-capacity battery, the LG300 is ideal for persistent tracking of vehicles or cargo, and the device also supports remote monitoring of your assets via SMS or network.

LG300 | An Upgrade of AT4

For more information

Specification

Network

Standard	4G LTE Cat.4
Bluetooth	BLE 4.0
Band	LTE-FDD: B2/B3/B4/B5/B7/B12/B17
	LTE-TDD: B38/B41 (100M)
	WCDMA: B2/B4/B5
	GSM: B2/B5/B8

Camera

Front Camera (Main)	1920×1080/25FPS/F2.2/Full color/85° (HFoV)
Peripheral Camera (Optional)	CIO1: 1280×720/15FPS/F2.0/Full color in daytime & monochrome in dim light/100° (HFoV)
	CIO3: 1280×720/15FPS/F2.4/Full color in daytime & monochrome in dim light/119° (HFoV)
	CE01: 1280×720/15FPS/F2.0/Full color/IP67/125° (HFoV)
	JC170: 1280×720/15FPS/F2.4/Monochrome/56° (HFoV)
Video Format	.ts & .mp4

Configuration

GNSS	GPS
Sensor	3-axis
Microphone	Support
Speaker	Support
Interface	Micro USB1, SOS1, TTL1, Relay1
Memory Support	TF card (Up to 256GB)
SIM Card Type	Nano
LED Indication	Red (Power), Blue (Cellular), Green (GPS)

Others Specs

Power Supply	Power cable: B+/ACC/GND
Operating Voltage	DC 9–30V
Operating Temperature	–20°C to +65°C
Storage Temperature	–30°C to +85°C
Device Weight	233g
Device Dimension	1096952mm
Certifications	CE/FCC/RoHS
